CAPSULE HEAD
Documents
- GBF
- TDS
Description and Application
SUPREME ELEMENTED DET is a delayed capsule head designed for use by combining it with a shock tube and rubber casing of the required length. It is used to produce non-electric capsules. There are primarily four types of Elemented DET, namely Type A, Type B, Type C, and Type D. The first two, Type A and Type B, are designed for surface mainline use. They are produced with low energy and millisecond delay. Type C and Type D are used for downhole applications.
Technical Specifications
| PRODUCT | TYPE A | TYPE B | TYPE C | TYPE D |
| Case Material | Aluminum | Aluminum | Aluminum | Aluminum |
| Usage Condition | Surface (STL) | Surface (STL) | Downhole (DTH) | Long Delay Downhole (LPD) |
| Capsule Power | Only Primary Charge | Very Low | No:8 | No:8 |
| Delay Range (ms) | 9 – 200 range | 9 – 200 | 200 – 600 | 100 – 9,000 |
